Explosion Containment

When pressure can’t escape, structure takes the hit — and wins.

Containment-rated housing and flanged access cover

What Containment Does

In a deflagration, flame speed and pressure rise rapidly. Containment designs the vessel or housing to survive that event intact. Walls, heads, doors, inspection ports, fasteners, and supports are verified to resist internal pressure and impulse, so the incident remains a controllable, inspectable event—not a catastrophic failure.

Where Containment Fits Best

  • Indoor equipment where external flame jet or debris is unacceptable.
  • Process areas with personnel adjacency, tight clearances, or zoning constraints.
  • Equipment with hygiene or product-integrity requirements where venting or suppression media is undesirable.
  • Critical assets that must be brought back online quickly after inspection.

Design Inputs We Consider

  • Material properties: Kst, Pmax, MEC, MIT/MIE, dust concentration and dispersion.
  • Geometry & construction: wall thickness, joints, flanges, doors, viewports, gaskets, anchors, supports.
  • Target Pred: coordination with prevention, isolation, and suppression where used.
  • Load cases: internal peak pressure, pressure-time impulse, cyclic loads, and thermal effects.

ATEX Engineering Services

  • Structural analysis: hand calcs, FEA, fatigue and fastener checks, nozzle/penetration analysis.
  • Detailed design: reinforcement schemes, collars/rings, clamp systems, hinges, blast latches, access doors.
  • Documentation: drawings, bill of materials, calculation package, and engineering stamp where required.
  • On-site services: fit-for-purpose surveys, inspection plans, and commissioning support.
Containment-rated housing and flanged access cover

Reinforcing, Installation & Certification

Through qualified partners, ATEX delivers complete reinforcing installation and certification. That includes fabrication of rings and stiffeners, field welding or mechanical fastening, anchor upgrades, torque/bolt-stretch procedures, pressure testing where applicable, and final sign-off to your jurisdictional requirements.

Standards & Good Practice

  • NFPA 69 — active explosion protection and coordination with isolation/suppression.
  • NFPA 652 — DHA, management systems, and protection layer selection.
  • NFPA 68 — venting coordination when hybrid strategies are used.
  • Applicable ASME/CSA practice for pressure-retaining components and inspection.

Hybrid Strategies

Containment is often paired with isolation to stop flame and pressure from migrating, and with suppression to reduce peak pressure inside the enclosure. We design these layers together so sensors, logic, and structures act as one system.

Project Flow

  1. Assessment: site survey, data collection (materials, geometry, current ratings), and DHA alignment.
  2. Engineering: calcs/FEA, reinforcement design, drawings, and stamped package.
  3. Installation: partner-delivered reinforcing, anchors, doors/latches, QA/QC and inspection.
  4. Certification & Handover: documentation set, operating envelope, inspection schedule.

Maintenance & Inspection

  • Routine visual checks for deformation, fastener condition, gasket integrity.
  • Scheduled torque verification and non-destructive examinations as specified.
  • Post-event inspection protocol and fast-return procedures.

Ready to Move Forward?

Let’s design the failure that never happens.
